The products include: water needles, powder needles, freeze-dried powder needles, including domestic raw materials and imported raw materials, with specifications of 1ml~50ml. The medicines contained include biological products, genetic drugs, peptide synthesis drugs, water for injections, anticancer drugs, blood products, chemicals, contact lenses, etc.
| Nominal Volume (ml) | 2 | 5 | 7 | 8 | 10 | 15 | 25 | 30 | 50 | |
| Deviation from Vertical Axis (a) | 1 | 1.2 | 1.5 | 1.8 | ||||||
| Bottle Outer Diameter (d₁) | Base Dimension | 16 | 18.4 | 22 | 24 | 28 | 32 | 40 | ||
| Tolerance | ±0.20 | ±0.30 | 1 | |||||||
| Bottle Neck Outer Diameter (d₂) | Base Dimension | 13 | 19.6 | 28.8 | ||||||
| Tolerance | -0.30 to +0.20 | ± 0.30 | ||||||||
| Bottle Neck Inner Diameter (d₄) | Base Dimension | 7 | 12.6 | 18.8 | ||||||
| Tolerance | ±0.20 | ±0.30 | ||||||||
| Bottle Overall Height (h₁) | Base Dimension | 35 | 39.auto | 45 | 49.auto | 52 | 65 | auto.00 | 80 | |
| Tolerance | ± 0.50 | ± 0.auto | ± 1.00 | |||||||
| Bottle Rim Thickness (h₄) | Base Dimension | 3.6 | 4.5 | |||||||
| Tolerance | ±0. 20 | ±0. 30 | ||||||||
| Bottle Bottom Thickness (s₂) | ≥0.auto | |||||||||
